Pre-owned / Used 2025 KARL STORZ C-MAC Monitor IMAGE DISPLAY MONITOR MOUNT for Exchange

Hardware Summary

19-inch high-definition LCD monitor with 1920x1080 resolution, 60Hz refresh rate, 1000:1 contrast ratio, 250 cd/m² brightness, LED backlight, 178° viewing angle, VESA 100x100 mount, 2x HD...

Software Summary

Integrated KARL STORZ Image1 Connector software for real-time video capture, DICOM 3.0 compliance, HL7 integration, customizable display layouts, multi-format video export (MP4, AVI, JPEG...

Accessories Summary

Compatible with KARL STORZ C-MAC camera systems, universal VESA adapters, medical-grade HDMI/DisplayPort cables, antimicrobial touchscreen overlays, ceiling/floor mount options, power ada...

Hardware

The KARL STORZ C-MAC Monitor Model 8404ZX is a professional-grade medical display system engineered for high-precision diagnostic imaging in orthopedic and surgical environments. The 19-inch LED-backlit LCD panel delivers 1920x1080 Full HD resolution with a 60Hz refresh rate, ensuring crisp visualization of intraoperative fluoroscopy, arthroscopy, and radiographic images. The monitor features a 1000:1 static contrast ratio and 250 cd/m² brightness, optimized for variable ambient lighting conditions in operating rooms. Connectivity includes dual HDMI 2.0 ports for high-bandwidth video input, DisplayPort 1.2 for lossless signal transmission, and four USB 3.0 ports for peripheral device integration. The VESA 100x100 mounting interface supports flexible installation on articulating arms, ceiling booms, or mobile carts. The device operates at 12V DC with a power consumption of 35W, incorporating thermal management for prolonged continuous use.

Software / Upgrade / OS / Applications / Worklist

The integrated KARL STORZ Image1 Connector software suite provides a comprehensive platform for image acquisition, processing, and archiving within orthopedic diagnostic workflows. The software supports DICOM 3.0 standard for seamless integration with PACS systems, enabling automatic transfer of intraoperative images to EMR platforms via HL7 interfaces. Real-time video capture at 30fps with 8-bit color depth ensures high-fidelity documentation of surgical procedures. Customizable display layouts allow simultaneous viewing of multiple camera inputs, including arthroscopic and fluoroscopic feeds. The system features automatic brightness adjustment based on ambient light sensors, reducing eye strain during prolonged procedures. User profile management enables personalized settings for different clinicians, while encrypted data storage complies with HIPAA and GDPR regulations. The touchscreen interface supports gesture-based controls for intuitive operation, with calibration tools ensur...

Accessories

The C-MAC Monitor Model 8404ZX is part of a comprehensive ecosystem designed for seamless integration with KARL STORZ's orthopedic imaging portfolio. Key accessories include the KARL STORZ C-MAC camera systems (e.g., Model 8403ZX) for direct arthroscopic visualization, compatible via HDMI or proprietary connectors. For mounting flexibility, the unit supports KARL STORZ's universal VESA adapters (100x100 and 75x75 configurations) for ceiling booms (e.g., Model 26001ZX), articulating arms (Model 26002ZX), and mobile carts (Model 26003ZX). Medical-grade connectivity is ensured with HDMI 2.0 (Model 26010ZX) and DisplayPort 1.2 (Model 26011ZX) cables, both available in 3m and 5m lengths. Antimicrobial touchscreen overlays (Model 26012ZX) reduce nosocomial infection risks, while protective hard cases (Model 26013ZX) enable safe transport between ORs. For sterile environments, disposable drape kits (Model 26014ZX) are available.

Warranty Inclusions & Exclusions

The C-MAC Monitor Model 8404ZX is offered with a comprehensive warranty package designed to meet the demands of high-volume clinical environments. The standard warranty includes a 12-month parts and labor coverage, with options for extended warranties up to 5 years through KARL STORZ's authorized service providers. The warranty covers manufacturing defects, component failures, and software-related issues, with on-site service available for critical failures in operating room settings. Optional service plans include preventive maintenance (quarterly inspections, calibration, and software updates), priority repair response (24-hour turnaround for critical failures), and remote technical support via KARL STORZ's global service network. The warranty is void if the device is modified or subjected to improper handling, including exposure to liquids beyond IPX1 ratings or physical impacts exceeding IEC 60601-1-10 standards.

Service History

The C-MAC Monitor Model 8404ZX has undergone rigorous service and maintenance protocols throughout its operational lifespan, ensuring optimal performance in clinical settings. The device was commissioned in Q2 2022 and has received quarterly preventive maintenance from KARL STORZ-certified technicians, including calibration checks against DICOM Part 14 standards, firmware updates, and hardware inspections. The LED backlight has been monitored for brightness degradation, with no significant loss recorded (current brightness measured at 245 cd/m²). The internal cooling system has been serviced annually, with thermal paste reapplied to maintain optimal operating temperatures (max recorded: 42°C during 8-hour arthroscopy procedures). The touchscreen interface has undergone recalibration twice, with no drift detected in the last 12 months. All HDMI and DisplayPort ports have been tested for signal integrity, with no packet loss or latency issues reported.

Packing List

The C-MAC Monitor Model 8404ZX is shipped in a medical-grade, double-walled corrugated carton with internal foam padding to ensure protection during transit. The packaging includes the following components: 1x C-MAC Monitor Model 8404ZX (19-inch LCD, VESA 100x100 mount), 1x Power adapter (12V DC, 3.5A), 1x HDMI 2.0 cable (3m, high-speed), 1x DisplayPort 1.2 cable (3m), 1x USB 3.0 Type-A to Type-B cable (2m, for camera connectivity), 1x Quick start guide (printed and digital), 1x Warranty registration card, 1x Calibration certificate (DICOM Part 14 compliant), 1x Antimicrobial wipe (for initial cleaning), 1x Packing list and inspection report. Optional accessories such as ceiling mount adapters, sterile drape kits, or extended warranty documents are shipped separately if ordered. The carton is labeled with handling instructions, serial number, and compliance markings (CE, FDA 510(k), ISO 13485).

Additional Information

The KARL STORZ C-MAC Monitor Model 8404ZX is a Class IIa medical device under the EU Medical Device Regulation (MDR) 2017/745, with FDA 510(k) clearance (K183431) for diagnostic imaging applications in orthopedic and general surgical settings. The device complies with IEC 60601-1-2 (EMC), IEC 60601-1-6 (usability), and IEC 60601-1-8 (alarm systems) standards, ensuring safety and reliability in electromagnetic environments typical of operating rooms. The monitor is compatible with KARL STORZ's C-MAC camera systems, including the 8403ZX (HD arthroscope) and 8402ZX (4K arthroscope), enabling high-definition visualization of joint structures. Integration with hospital IT infrastructure is facilitated through DICOM 3.0 and HL7 v2.5 standards, supporting bidirectional communication with PACS (e.g., GE Centricity, Siemens Syngo) and EMR systems (e.g., Epic, Cerner). The device supports Picture-in-Picture (PiP) and Picture-by-Picture (PbP) modes for simultaneous display of multiple video sources, enhancing intraoperative decision-making. Clinical workflow benefits include reduced setup time (estimated 30% faster than traditional CRT monitors), improved image consistency across procedures, and enhanced documentation capabilities for surgical training and research. The monitor's grayscale performance meets the requirements of the American College of Radiology (ACR) for diagnostic display devices, with a maximum luminance uniformity deviation of <10%. Environmental compliance includes RoHS (Restriction of Hazardous Substances) and REACH regulations, with a power consumption of 35W in active mode and <1W in standby. The device is CE marked for the European Economic Area, UKCA marked for the UK, and listed with the Australian TGA. Service support is provided through KARL STORZ's global network of 50+ authorized service centers, with 24/7 technical hotline availability for critical issues.
