Pre-owned / Used 2017 KARL STORZ IMAGE 1 H3-Link TC 300 TC 200 ENDOSCOPIC VIDEO IMAGING SYSTEM for Sale

Hardware Summary

4K UHD resolution, 300W xenon light source, 3-chip CMOS sensor, 200° field of view, 3D-capable, autoclavable instruments, LED indicator for lamp status, integrated insufflation pump, 12G ...

Software Summary

IMAGE1 PILOT software suite, 4K real-time processing, HDR imaging, auto-white balance, image enhancement algorithms, DICOM 3.0 compliance, HL7 integration, touchscreen GUI, multi-language...

Accessories Summary

Full Karl Storz endoscopic instrument compatibility, IMAGE1 H3-Link camera head, IMAGE1 TC 300 light source, IMAGE1 TC 200 control unit, sterile drapes, biopsy forceps, irrigation pumps, ...

Hardware

The Karl Storz IMAGE 1 H3-Link TC 300 TC 200 endoscopic video imaging system represents a state-of-the-art platform designed for high-definition diagnostic and therapeutic procedures in pathology and related specialties. The system features a 4K UHD (3840 x 2160 pixels) resolution imaging chain with a 3-chip CMOS sensor providing exceptional color fidelity and depth perception. The integrated 300W xenon light source delivers consistent illumination with color temperature stability of 6000K ± 300K, ensuring accurate tissue visualization. The TC 300 light source incorporates an advanced cooling system with thermal cut-off protection and a lamp life indicator displaying remaining usage hours. The TC 200 control unit provides comprehensive image processing capabilities including real-time noise reduction, edge enhancement, and adaptive contrast enhancement algorithms. The system supports both 2D and 3D endoscopic imaging through compatible Karl Storz 3D scopes, with passive and active p...

Software / Upgrade / OS / Applications / Worklist

The IMAGE1 PILOT software suite provides a comprehensive platform for endoscopic imaging with advanced processing capabilities. The system runs on a proprietary real-time operating system optimized for low-latency image processing, achieving less than 8ms end-to-end latency in 4K mode. The software supports multiple imaging modes including standard white light, narrow band imaging (NBI), blue light imaging (BLI), and linked color imaging (LCI) for enhanced tissue characterization. Advanced features include auto-exposure control with scene-adaptive algorithms, dynamic range expansion up to 120dB, and real-time histogram equalization. The system incorporates DICOM 3.0 compliance for seamless integration with PACS systems, supporting both storage and query/retrieve services. HL7 version 2.5 interface enables bidirectional communication with hospital information systems for patient data management and procedure documentation.

Accessories

The Karl Storz IMAGE 1 H3-Link TC 300 TC 200 system is compatible with a comprehensive ecosystem of endoscopic instruments and accessories designed for pathology applications. Primary components include the IMAGE1 H3-Link camera head with 4K CMOS sensor and 12G SDI output, IMAGE1 TC 300 xenon light source with 300W output and color temperature stabilization, and IMAGE1 TC 200 control unit with integrated insufflation pump and video processing capabilities. The system supports all Karl Storz 10mm and 5mm rigid endoscopes with 0°, 30°, and 70° viewing angles, including specialized models for ENT, urology, and gynecology applications. Compatible biopsy forceps include FB-231K, FB-232K, and FB-233K models with 2.0mm, 2.4mm, and 3.0mm cup diameters respectively. The system requires specific light cables including the 495NL light cable for xenon sources and 495NLA for LED compatibility. For 3D imaging applications, the system supports Karl Storz 3D endoscopes with passive (STORZ 3D) and a...

Warranty Inclusions & Exclusions

This pre-owned Karl Storz IMAGE 1 H3-Link TC 300 TC 200 endoscopic video imaging system is offered with comprehensive warranty coverage options to ensure clinical reliability and operational continuity. The seller provides a minimum 12-month limited warranty covering all original equipment components against manufacturing defects, with optional extended warranty periods available at additional cost. The warranty includes replacement of defective parts, labor for repairs, and on-site service calls where applicable. The warranty covers the camera head, control unit, light source, and all integrated components, excluding consumables such as lamps, light cables, and sterile drapes. Service response time is guaranteed within 48 business hours for critical failures affecting clinical operations, with standard response time of 5 business days for non-critical issues. The warranty includes comprehensive diagnostic testing using Karl Storz's proprietary service software to verify system perf...

Service History

The Karl Storz IMAGE 1 H3-Link TC 300 TC 200 system has undergone comprehensive preventive maintenance and service procedures throughout its operational life, with detailed records available for review. The system has received regular professional servicing at intervals not exceeding 12 months as recommended by Karl Storz's service guidelines. Maintenance activities include complete system calibration using NIST-traceable test equipment, xenon lamp replacement at approximately 300-hour intervals, CMOS sensor cleaning and inspection, optical path alignment verification, and electrical safety testing per IEC 60601-1 standards. The camera head has undergone steam sterilization cycles totaling 150 procedures with no degradation in optical performance, verified through periodic MTF (Modulation Transfer Function) testing maintaining >50% contrast at 100 lp/mm. The TC 300 light source has received preventive maintenance including reflector cleaning, UV filter inspection, and cooling system...

Packing List

The Karl Storz IMAGE 1 H3-Link TC 300 TC 200 endoscopic video imaging system is delivered in a comprehensive packaging solution designed to ensure safe transportation and immediate clinical readiness. The primary packaging consists of a custom-fitted foam-lined aluminum case with dimensions 600mm (W) x 450mm (D) x 350mm (H) and weight 22kg, providing IP65 protection against dust and water ingress. The case includes a pressure equalization valve and desiccant packs to maintain optimal humidity levels during transport. The system components are individually secured with custom-cut foam inserts, including dedicated compartments for the TC 200 control unit, TC 300 light source, H3-Link camera head, and all accessories. The packing list includes the IMAGE1 TC 200 control unit with integrated insufflation pump, IMAGE1 TC 300 xenon light source with 300W lamp, IMAGE1 H3-Link 4K camera head with 12G SDI output, power cable set (100-240V AC), DVI-D to HDMI adapter, USB 3.

Additional Information

The Karl Storz IMAGE 1 H3-Link TC 300 TC 200 endoscopic video imaging system represents a premium-grade imaging platform with exceptional clinical utility in pathology and related diagnostic specialties. The system has received FDA 510(k) clearance under product code FTC for endoscopic imaging applications, with CE marking under the Medical Device Directive 93/42/EEC. The device complies with multiple international standards including IEC 60601-1 (Medical electrical equipment - General requirements for safety), IEC 60601-2-18 (Particular requirements for the safety of endoscopic equipment), ISO 13485 (Quality management systems for medical devices), and ISO 14971 (Application of risk management to medical devices). The system incorporates advanced imaging technologies including 4K UHD resolution with 3-chip CMOS sensors providing superior color reproduction and depth perception compared to conventional 2D systems. The integrated narrow band imaging (NBI) capability enhances visualization of mucosal and vascular patterns, particularly valuable in identifying early neoplastic changes in gastrointestinal and respiratory tissues. The system's 3D imaging capability supports enhanced depth perception during complex procedures, reducing procedure times and improving diagnostic accuracy. The IMAGE1 PILOT software suite provides comprehensive image processing with real-time capabilities, supporting multiple imaging modes including standard white light, NBI, blue light imaging (BLI), and linked color imaging (LCI). The system's DICOM 3.0 compliance enables seamless integration with hospital PACS systems for long-term image storage and retrieval, while HL7 integration supports bidirectional communication with electronic health records. The device incorporates multiple safety features including thermal cut-off protection for the xenon light source, automatic voltage adjustment for power input stability, and comprehensive electrical safety testing per IEC 60601-1 standards.
